Product Description
Avalon 700 Wood Stove - For use with 700 serial #'s 4063 to 5747 only!
This item is no longer available, the manufacture has stopped making them and we currently do not have another option available.
Air tube A-2. Includes 2 - 9-15/16" long secondary air tubes, 1 - 1-1/4" long retaining sleeve, 2 - 1/4" 1/4-20 SHSS, 1 - 1/8" hex key, 1 - 1/4" roll pin (#98900357) and 1 - instruction sheet.
Step 1: Remove the old airtube
1. Remove existing roll (retaining) pin by using the pointed end of the roll pin tool and a hammer to drive the roll pin into the center of the air tube. Refer to Diagram B
2. Slide the old airtube to the right as far as it will go. The left end should drop out of the retaining sleeve on the left side. Pull the left side down to clear the sleeve and pull the tube out of the right sleeve. You may need to clamp the pipe with Vise Grips™ and twist it as you pull it out. If you can not do this, then you will need to cut the tube in two, and then remove and discard the pieces.
Step 2: Install the replacement tube
1. Slide the left side airtube (1) into the left sleeve (air holes face forward). Slide the retainer collar over the left airtube. Refer to Diagram C.
2. Slide the right airtube (2) into the right sleeve (air holes face forward). Be sure the larger retaining pin holes in both the tube and sleeve line up.
3. Using the roll pin installation tool, install the roll pin into the hole in the sleeve to lock the air tube in place.
4. Slide the left side airtube (1) over to meet the right side air tube. Slide the retainer collar (3) to the right and center it over the joint between the two tubes. Using a 1/8" Allen (hex-key) wrench, firmly tighten
the two set-screws into the retainer collar
